Bosch Rexroth Corp.

Dec. 12, 2006
Catalog Features Pneumatic Components

The new Rexroth catalog SC-400.10 features 128 pages of technical and ordering information and features an overview section on inch and metric Series QR1 pneumatic push-in fittings. With the QR1 series, Rexroth provides a comprehensive inch and metric (ISO-G) program for its pneumatic components. In addition to the Mini and Standard programs, the complete fitting program also includes various function fittings.

Series QR1 (Quick Release) fittings are equipped with user-friendly oval plastic release rings that enable fast connection and release of compressed air tubing, making them easier to use than standard push-in fittings. The mini design has been created for plastic tubing ODs of 1/8” to ¼” and 3-6 mm. This variety of fittings is completely new at Rexroth and rounds out the product spectrum specifically for the small handling sector. The standard design fittings can be used for tubing ODs of 5/32” to ½” and 4-16 mm. Products such as check, ball and flow control valves are also included in the range of function fittings.
